Huarui VD-3CAM
Huarui

Huarui VD-3CAM

$180
8.4
โ˜…โ˜…โ˜…โ˜…โ˜† 8.4 Available
๐Ÿ“ก 3-Eye Camera
๐Ÿ“… 2023
๐Ÿ“ 2026-06-17 Review
๐ŸŽฏ Industrial Automation Logistics
Score Breakdown
8.2
Image Quality
8.5
Video Performance
7.8
AI Features
8
Build Quality
9.2
Value for Money
๐Ÿ›’ Place Order

Pros

  • Cost-effective; Three-camera design; Good for industrial use; IP65 option

Cons

  • Less known internationally; SDK docs primarily in Chinese; Smaller developer community
๐Ÿ“ Verdict

Excellent value industrial 3D camera, especially for cost-sensitive applications.

๐Ÿ“‹ Full Hardware Specifications

๐Ÿ“ก Multi-Eye System Specs
Eye Count (Camera Count) 3
Baseline Length (mm) 10cm
Depth Range (m) 0.3-8m
Depth Accuracy (mm) ยฑ3mm
Sync Mode Hardware (GPIO)
Optimal Working Distance (m) 0.1 - 8
๐Ÿ”ฌ Sensor Specifications
Sensor Model / Type Global Shutter CMOS ร—3
Sensor Size 1/2.8"
Per-Eye Resolution (MP) 1920ร—1080 ร—3
Max Frame Rate (FPS) 30 FPS
Shutter Type Global
Field of View (ยฐ) 70ยฐ(H) ร— 43ยฐ(V)
๐Ÿ”Œ Interface & Connectivity
Data Interface Ethernet, USB 3.0
Trigger Input Yes (GPIO/SDK)
Power Supply 5V/3A (USB 3.0)
OS Support Windows, Linux
๐Ÿ—๏ธ Physical & Environmental
Dimensions (mm) 130ร—60ร—45mm
Weight (g) 250g
IP Rating IP65 (optional)
Operating Temperature (ยฐC) -10 - 50
Housing Material Aluminum alloy (IP67)
Mounting Method M4 threaded holes & 1/4"-20 UNC
๐Ÿ’ก Features
ISP Processor External (PC required)
IR Filter 850nm/940nm selectable
HDR Support Not supported
Wide Dynamic Range (dB) 100
Point Cloud Output Yes
SDK VD SDK
๐Ÿ“ฆ Package Contents
What's in the Box
โ€ข Camera, USB3 cable, Power supply, SDK CD, Quick start guide
Warranty Period 1 year

Overview

The Huarui VD-3CAM is a professional-grade structured light 3D camera designed for industrial inspection and measurement applications. It delivers high-precision 3D point clouds with excellent repeatability for quality control in manufacturing environments.

Key Features

  • Structured light 3D scanning
  • High-precision 3D measurement
  • Working distance: 300mm – 1500mm
  • Point cloud resolution up to 12MP
  • Gigabit Ethernet interface
  • Industrial-grade housing
  • SDK for C++ and Python
  • Support for multi-camera setups

Performance

The VD-3CAM delivers consistently accurate 3D measurements suitable for dimensional inspection and quality control. In our factory floor tests, it maintained precision despite varying ambient light conditions. The multi-camera synchronization enables full 360-degree scanning of objects.

Pros and Cons

Pros: High measurement precision, good ambient light resistance, industrial build quality, multi-camera support, competitive pricing.

Cons: Slower capture speed than ToF alternatives, limited SDK documentation in English, smaller community, fewer integrations.

Verdict

The Huarui VD-3CAM offers excellent value for industrial 3D measurement applications. Its combination of precision and competitive pricing makes it a strong contender for quality control and inspection tasks.
